Mechanical Shearing Under Crank Machine

Name: Mechanical Shearing Under Crank Machine
Brand: VICTORY MACHINERY CORPORATION
Price: 450000 INR
Availability: InStock

Price 450000 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Mechanical Shearing Under Crank Machine Specification

Type
Mechanical Shearing Under Crank Machine

Material
Mild Steel Body

Capacity
Up to 6 mm Thickness

Computerized
No

CNC Or Not
Not CNC

Automatic Grade
Manual / Semi-Automatic

Control System
Hand / Foot operated

Cutting Size
Variable, up to 2500 mm

Cutting Thickness
Upto 6 mm

Cutting Width
1250 mm / 2000 mm / 2500 mm

Blade Material
HCHCr / Alloy Steel Blade

Voltage
415V, 3 Phase

Power
3 HP / 5 HP

Dimension (L*W*H)
3200 x 1350 x 1500 mm (for 2500 mm model)

Weight
2200 kg 3500 kg (depending on model)

Color
Industrial Green with Yellow highlights

Hold Down Mechanism
Spring Loaded Mechanical Hold Down

Safety Features
Mechanical Interlock and Safety Guards

Lubrication System
Manual or Centralized Lubrication

Motor RPM
1440 RPM

Shearing Length
1250 mm / 2000 mm / 2500 mm

Application
Sheet Metal Cutting in Industries

Working Table Height
850 mm (Approx.)

Stroke Per Minute
20 to 25

Operation Mode
Foot Switch / Push Button

Standard Accessories
Motor Pulley, Starter, V-Belts

Back Gauge Range
600 mm

Frame Type
Rigid, Welded Steel Plates

Blade Clearance Adjustment
Provided

Bed Width
500 mm to 800 mm

Mechanical Shearing Under Crank Machine Trade Information

Minimum Order Quantity
1 Unit

Main Domestic Market
Gujarat, Karnataka, Madhya Pradesh, Maharashtra, Tamil Nadu

About Mechanical Shearing Under Crank Machine

Product details

Colour	Blue
I Deal In	New Only
Location	Pan India
Country Of Origin	Made In India
Automation Grade	Automatic
Material	SS

Specification

Model	Cutting CAP. In MS Length x Thickness	Stroke per Minute	Table Height	Table Width	Front Gauge	Rear Gauge	Motor HP/KW
TUS-122	1270x2	45	800	350	750	500	2
TUS-152	1525x2	45	800	350	750	500	2
TUS-202	2030 x2	45	800	350	750	500	3
TUS-252	2540 x2	45	825	430	980	500	5
TUS-312	3150x2	45	825	430	980	500	M
TUS-124	1270x4	50	825	430	980	500	> 5
TUS-154	1525x4	50	825	430	980	500	5
TUS-204	2030x4	50	825	430	980	500	7.5

Precision Shearing for Industrial Needs

Built with a rigid, welded steel body and a dynamic under crank drive, this mechanical shearing machine serves all major sheet metal cutting demands in workshops and production plants. Blade clearance adjustment and mechanical hold down ensure precise, burr-free cuts, while the variable cutting sizes and robust construction accommodate diverse fabrication tasks.

Easy Operation and Versatile Control

The machine features both hand and foot-operated control systems, supporting manual and semi-automatic requirements. The simple foot switch or push button allows for efficient and safe operation, even with repetitive shearing cycles, and comes with standard accessories including starter, motor pulley, and V-belts.

Enhanced Safety and Low Maintenance

Safety is integral, thanks to the mechanical interlocks and protective guards. The lubrication systemmanual or centralizedensures smooth performance with minimal downtime. The durable HCHCr/alloy steel blades, coupled with an ergonomic working table height (850 mm), provide comfortable and secure usage for extended daily operations.

FAQs of Mechanical Shearing Under Crank Machine:

Q: How does the blade clearance adjustment benefit the shearing process?

A: By enabling fine-tuned blade clearance, operators can achieve clean, accurate cuts across a range of sheet thicknesses up to 6 mm, reducing burrs and material deformation, thus ensuring optimal results in metal fabrication.

Q: What is the operational process of the foot switch and push button control modes?

A: The machine offers both foot switch and push button operation, allowing users to control shearing cycles hands-free or with a simple touch, increasing productivity and safety by providing flexibility according to the operators preference.

Q: When should the lubrication system be used, and what options are available?

A: Regular lubrication is recommended as per the manufacturers schedule to maintain smooth machine action. The system supports both manual and centralized lubrication, making it adaptable for different workshop maintenance routines.

Q: Where can this shearing machine be applied within industries?

A: This machine is ideal for sheet metal fabrication units, workshops, manufacturing plants, and any industrial setting requiring precise and efficient cutting of steel sheets, especially for lengths up to 2500 mm and thicknesses up to 6 mm.

Q: What are the main safety features of this mechanical shearing machine?

A: To ensure operator protection, the machine includes mechanical interlocks and safety guards which minimize accidental contact with moving parts during operation, making the machine compliant with industry safety standards.

Q: How is the working table height advantageous for users?

A: With a table height of approximately 850 mm, the machine offers an ergonomic working position, reducing operator fatigue during repeated shearing cycles and allowing comfortable handling of sheet materials.
